CNCMC TRS18/20 18/20 Ton Single Drum Road Roller

CNCMC TRS18/20 18/20 Ton Single Drum Road Roller Featured Image
  • CNCMC TRS18/20 18/20 Ton Single Drum Road Roller

Introduction:

         5 Core Advantages of 18T / 20T Single-Drum Roller

  • Extra strong compaction force for high-density subgrade.
  • Excellent traction and stability on uneven sites.
  • High efficiency for large earthwork and roadbase projects.
  • Heavy-duty structure with high reliability.
  • Ideal for major roads, airports and large infrastructure.


Product Detail

Product Tags

Specification   TRS18 TRS20
Operating mass kg 18000 20000
Static linear load N/cm 470 500
Vibration amplitude mm 1.9/0.95 1.9/0.95
Vibration frequency Hz 28/35 28/35
Centrifugal force kN 390/280 410/300
Travel speed Km/h 11/4.9/2.5 11/4.9/2.5
Gradeability % 30 30
Turning radius mm 7500 7500
Drum width mm 2100 2100
Drum diameter mm 1600 1600
Wheelbase mm 3380 3380
Ground clearance mm 400 400
Diesel engine model 　 WP6G190E301 WP6G190E301
Diesel engine power kW 140 140
Overall dimensions mm 6665x2280x3090 6665x2300x3090
