CNCMC Best Selling Articulated TB470 75Kw 4X4 Small Backhoe Loaders

Introduction:

Optimal Power and Efficiency

TB470 75 kW of power, it delivers strong performance for digging, loading, and lifting tasks while maintaining good fuel efficiency.

Multi‑Functionality

Equipped with a front loader and rear excavator, it can handle loading, digging, grading, breaking, and lifting—reducing the need for multiple machines.

Excellent Maneuverability

Its compact size and tight turning radius make it ideal for urban construction, narrow job sites, and utility work.

Lower Operating Costs

The 75 kW engine offers a balance of power and fuel economy, and maintenance costs are generally lower compared to larger excavators or loaders.

Easy Mobility and High Utilization

As a self‑propelled machine, it can move between job sites without a trailer, improving efficiency and reducing downtime.

Inquiry

Product Detail

Product Tags

The Main Performance Parameter of Backhoe Loader TB470
Overall Operating Weight	7640KG	Final Reducer	Single Stage Final Reducer
Transport Dimension		Rated Loader of Axle	7.5t
*LWH（mm）*	5910×2268×3760	Transmission System
Wheel base	2250mm	Torque Converter
Min. Ground Clearance	300mm	Model	YJ280
Bucket Capacity	1.2m3	Type	Single-stage Three Elements
Breakout Force	38KN	Max. Efficiency	84.4%
Loading Lifting Capacity	2500KG	Inlet Pressure	0.4Mpa—0.55 Mpa
Bucket Dumping Height	2742mm	Outlet Pressure	1.2Mpa—1.5 Mpa
Bucket Dumping Distance	1062mm	Cooling Method	Oil-cooling Pressure Circulation
Digging Depth	52mm	Gearbox
Backhoe Capacity	0.3m3	Type	Fixed Shaft Power Transmission
Max. Digging Depth	4082mm	Oil Pressure of Clutch	1373Kpa—1569 Kpa
Swing Angle of Excavator Grab	190o	Gears	Two Gears Ahead, Two Gears Astern
Max. Pulling Force	39KN	Max.Speed	22Km/h
Engine		Tyre
Model	CYD YC4A105Z-T20	Model	16/70-20
Type	In Line Direct injection Four-Stroke and Injection Combustion Chamber	Pressure of Front wheel	0.22 Mpa
*Cylinder-Inside DiameterStroke**	4-102×120	Pressure of Back Wheel	0.22 Mpa
Rated Power	75KW	Brake System
Rated Speed	2200r/min	Service Brake	Air Over Oil Caliper Brake
Min. Fuel Consumption	≤216g/km.h		External Type
Max.Torque	≥410N.M/1500r/min		Self-regulation
Displacement	3.9L		Self-balance
Steering System		Emergency Brake	Operation Power Implementing brake
Model of Steering Device	BZZ5-250		Manual Operation Power Terminating Brake
Steering Angle	±36 o	Hydraulic System
Min. turning radius	5018mm	Digging Power of Excavator Grab	46.5KN
Pressure of the system	12Mpa	Digging Power of Dipper	31KN
Axle		Bucket Lifting Time	5.4S
Manufacturer	Feicheng Axle Factory	Bucket Lowering Time	3.1S
Main Transmission Type	Double Reduction	Bucket Discharge Time	2.0S
