CNCMC CPCD250 25 Ton Diesel Forklift Truck

Introduction:

25-ton ultra-heavy capacity for large heavy-duty cargo handling.
High-power engine with strong power and stable operation.
Heavy-duty reinforced frame, high rigidity and safety.
Suitable for ports, steel mills, mines and heavy industrial sites.
High working efficiency, durable and low operation cost.

Product Detail

Product Tags

Specification		CPCD250
Rated capacity	kg	25000
Load centre	mm	1220
Front overhang	mm	1200
Rear overhang	mm	4500
Total weight (unladen)	mm	36400
Front axle loading/ rear axle loading (laden)	mm	56940/4460
Front axle loading/ rear axle loading (unladen)	mm	18500/17900
Tyres stype		Pneumatic
Front tyre size		14.00-24 28PR
Rear Tyre size		14.00-24 28PR
Wheels number，front/rear（x=driving wheel）		X4/2
Track width (front tyre)	mm	2200
Track width (rear tyre)	mm	2300
Mast tilt angle	°	6/12
Overall height (fork lowered, upright)	mm	4255
Free lift	mm	0
Max. lift height of forks	mm	4000
Overall height fork raised	mm	6270
Overhead guard height	mm	3580
Closed cabin height	mm	3580
Seat height	mm	2220
Drawbar coupling height	mm	785
Rear overhang	mm	1100
Overall length (include fork)	mm	9240
Overall length to fork face	mm	6800
Overall width	mm	3020
Fork size (Thick/width/length)	mm	110/300/2440
Forks bracket stype		Side shift /fork shift
Width of bracket	mm	3020
Forks width, outside，Max./Min.	mm	1040/2660
Side shift distance @forks’ outside	mm	0-405/1930
Ground clearance under mast（laden）	mm	300
Ground clearance, centre of wheelbase（laden）	mm	340
Goods size	mm	2440/2440
Min. aisle width for crossway（200mm space）	mm	9820
Min. aisle width for crossway（10% space）	mm	10580
Min. turning radius	mm	6100
Driving speed，laden/unladen		28/26
Lifting speed，laden/unladen		0.3/0.33
Lowering speed，laden/unladen		0.33/0.32
Drawbar pull，laden/unladen（1.6km/h）		150/150
Drawbar pull，laden/unladen（idle speed）		160/160
Gradeability，laden/unladen（idle speed）		25/30
