CNCMC CPCD30 3 Ton Diesel Forklift Truck

CNCMC CPCD30 3 Ton Diesel Forklift Truck Featured Image
  • CNCMC CPCD30 3 Ton Diesel Forklift Truck

Introduction:

  • Standard 3-ton capacity, suitable for most heavy handling work.
  • Strong diesel power, reliable for outdoor and heavy-duty operation.
  • Stable structure, safe lifting and high working efficiency.
  • Wide application in factories, warehouses, docks and logistics yards.
  • Durable, easy maintenance and high cost-performance.


Product Detail

Product Tags

Specification   CPCD30
 Fuel type   Diesel
Load capacity kg 3000
Load center mm 500
Lift height mm 3000
Free lift height mm 100
Fork size mm 1070x125x45
Fork length mm 1075
Tilting angle Deg 6/12
Min.turning radius mm 2400
Groud clearance Mast mm 135
Chassis mm 140
Overhead guard mm 2165
The second mast height mm 3950
Front overhang mm 490
Rearoverhang mm 555
Max travel speed km/h 20
Max lift speed mm/s 480
Max.traction power KW 20
Max. gradeability % 20
Length With fork mm 3770
Without fork mm 2700
Width mm 1225
Mast extended height mm 4265
Mast lowered height mm 2065
Tires Front   28×9-15-12PR
Rear   6.50-10-10PR
Wheelbase mm 1700
Tread mm 1000/970
Service weight Kg 4350
Battery V/Ah 12/80
Engine Model   Xinchai 490
Power kw/r.p. 40/2650
Transmission   Hydraulic, 1/1
Operating pressure Mpa 18.5
