CNCMC PC100 1 ton Demolition Robot

Compact and lightweight, suitable for narrow and confined working spaces.
Remote control operation ensures high safety and protects workers from risks.
Flexible movement and strong breaking capacity for efficient demolition work.
Low energy consumption and easy maintenance, reducing operating cost.
Wide application in demolition, crushing, rescue and indoor reconstruction projects.

Product Detail

Basic performance
Hammer model	PC100
Work radius	3.5m
Grade ability	30°
Rotary speed/range	6rpm/360°
Max walking speed	2.5km/h
Outrigger	4,frog type
Noise level	85.8dB(A)
Weight	1050kg
Dimension(LxWxH)	1900x800x1200(mm)
Hydraulic system
Drive mode	Electron-hydraulic proportional
Hydraulic pump Type	Load sensitive variable axial piston pump
Hydraulic valve type	Electron-hydraulic proportional valve
Hydraulic system capacity	40L
Max flow rate of hydraulic pump	50L/min
System pressure	16Mpa
Power system
Power option I	Diesel engine 16Kw/2100rpm
Power option 2	Electric motor 14Kw
Start mode	Soft start
Control system
Operation	Portable remote controller
Signal mode	Digital
Control mode	Wired/wireless
Remote control distance	200m
