CNCMC TD22 220hp Crawler Bulldozer

Introduction:

Strong power & traction – 220HP engine ensures excellent pushing and climbing performance.
High working efficiency – Faster operation and larger earthmoving volume per hour.
Versatile for tough conditions – Adaptable to construction, mining, land leveling and heavy-duty working sites.
Stable & durable – Rugged structure and reliable parts for long-term heavy use.
Cost-effective – Balanced power and fuel consumption, low operating and maintenance cost.

Product Detail

Product Tags

SPECIFICATION	TD22			WORK EQUIPMENT
Specification / Blade type	Straight-tilt	Angle	U-Blade	Specification/Blade type	Straight-tilt	Angle	U-Blade
Operating Weight(kg)	23400	23650	24500	Blade Capacity(m³）	6.5	4.8	7.5
Min.Ground Clearance(mm)	405	405	405	Blade Width XHeight(mm)	3725X1315	4365X1055	3800X1343
Min.Turning Radius(m)	3.3	3.3	3.3	Max.Lift(mm)	1210	1300	1210
Ground Pressure(MPa)	0.077	0.077	0.073	Max.Depth(mm)	540	530	540
Track Gauge(mm)	2000	2000	2000	Max.Tilt Adjustment(mm)	≥735	≥500	≥540
Max.Pulling Force(KN)	202	202	202	Pitch Adjustment(°)	55	53.5	55
Climb Angle(°)	30	30	30	Capability(myh)	330	245	365
TRAVEL SPEED				Weight Of Blade(kg)	3630	3850	4200
	1st	2nd	3rd	COOLANT AND LUBRICANT CAPACITY
Forward(km/h)	0~3.6	0~6.5	0~11.2	Fuel Tank Capacity(L)	480
Reverse(km/h)	0~4.3	0~7.7	0~13.2	Hydraulic Tank Capacity(L)	110
ENGINE				Engine Oil Capacity(L)	45
Model&Type	Cummins NT855-C280S10			Final Drive Capacity(L)	72(each side)
	6-cylinder, In-line, 4-stroke-cycle,water-cooled,			RIPPER(OPTIONAL)
	overhead valve direct injection,turbocharged diesel			3-Shank Ripper:
Rated Revolution(rpm)	2000			Max.Digging Depty(mm)	666
Flywheel Horsepower(HP)	220			Max,Lift(mm)	555
Cylinder Number-BoreXStroke(mm)	6-139.7X152.4			Shank Of Distance(mm)	1000
Piston Displacement(L)	14			Weight(kg)	2495
Min.Fuel Consumption(g/kWh)	≤212			Single Ripper:
Max.Torque(Nm/rpm)	1078/1250			Max.Depth(mm)	695
Starting Method	Starting motor 24V 11kW			Max.Lift(mm)	520
POWER TRANSMISSION SYSTEM				Weight(kg)	2453
Torque Converter	3-element,1-stage,1-phase
Transmission	Planetary gearing,hand-manipulated,hydraulic shift,forced lubrication,3forward and 3reverse speeds
Bevel Gear	Spiral bevel gear,splash lubrication,single-stage speed reduction
Steering Brake/Clutch	Wet,multi-disc, spring loaded,hydraulically separated, hydraulic control/Wet,floating, direct on-off hydraulic inter-linking operation
Final Drive	Double reduction of spur gear,splash lubrication
HYDRAULIC SYSTEM
Pump Type	Gear pump 07444-66103
Working Pressure(MPa)	14
System Discharge(L/min)	262(atrevollution of 2000rpm)
Working Cylinder type	Double-acting piston type
Working Cylinder lift Number-BoreXRodXStroke(mm)	2-120X70X1043
Working Cylinder Tilt BoreXRodXStroke(mm)	200X90X130
