CNCMC TD51 510hp Crawler Bulldozer
| ENGINE | VOLUME | ||
| Engine | Cummims QSX 15 | Fuel capacity | 920L |
| Emission | U.S.EPA Tier 3, EU Stage llIA | Coolant liquid capacity | 73L |
| Rated revolution | 1800rpm | Engine oil capacity | 45-49L |
| Gross power | 380kW(510hp) | Hydraulic oil tank (travel) | 370L |
| Net power | 343kW(460hp) | Hydraulic oil tank (work) | 43L/single side |
| No.of cylinder*bore*stroke | 6*137mm*169mm | Final drive | 8L |
| Displacement | 15L | Transfer case | 6L |
| Max.torque | 2365Nm@1400rpm | DIMENSION | |
| Cooling system | Smart temperature-controlled fan | Machine height | 3990mm |
| DRIVE SYSTEM | Track grouser height | 87mm | |
| Drive system | Independent dual-circuit electric controlhydrostatic drive, intelligent matching ofspeed load,”stepless”variable speed,mono-lever control of travel, speed andsteering; steering with load, pivot steering.work flexibly, high efficiency,easy formaintenance | Width from end of left track shoe to end of right trackshoe (standard) | 2870mm |
| System overflow pressure | 43500kPa | Machine length (with ripper) | 9325mm |
| Traveling speed(Forward-Backward) | 0~11km/h-0~11km/h | Machine length (without ripper) | 7085mm |
| Max.theoretical traction force | 720kN | Max. lifting height of blade | 1460mm |
| Steering | Independent drive of track at both sidesto ensure the full power output for pivotsteering and steering with load | Width from end of left footplate to end of right footplate(standard) | 3322mm |
| Brake | Regular closed multi-disk brake | Digging angle of blade | 53°±3°(deg.) |
| FINAL DRIVE | Double-reduction final drives of spur gearand planetary gear | Blade width | 4320mm |
| CHASSIS SYSTEM | Blade height | 1950mm | |
| Type | Pivot,equalizing beam suspended type,semi-rigid structure | Blade tilt height | 1140mm |
| Track shoe type | Single grouser | Ground clearance | 680mm |
| Track gauge | 2260mm | Max. digging depth of blade | 660mm |
| Width of track shoe | 610mm/660mm/710mm | RIPPER | |
| Track grounding length | 3532mm | TYPE | Single Shank ripper |
| Track grounding area | 21545cm2 | Weight | 3728kg |
| Number of track shoe | 40 pcs/side | Ripping Depth of Ripper | 1245mm |
| Grounding pressure (standard configuration)Number of carrier roller | 120kPa | Lifting Height of Ripper | 1056mm |
| Number of carrier roller | 2 pcs/side | Length of Ripper(Maximum Subsoiling Position) | 2475mm |
| Number of track roller | 7 pcs/side | Width of Ripper | 1490mm |
| Pitch | 260MM | Tilt Angle(Maximum Lift Position) | 37.5 |
| BLADE | OPERATING WEIGHT | ||
| Blade type | Rock Blade | Operating weight | 56000kg |
| Blade capacity | 13.7m³ |
