CNCMC TE150 15 Ton Crawler Excavator

Strong digging force and high efficiency for medium and heavy construction tasks.
Stable structure and strong load capacity for long-term reliable operation.
Balanced size, flexible enough for urban, road and municipal projects.
Wide adaptability to digging, loading, crushing and other working conditions.
Low fuel consumption and easy maintenance, reducing overall operation cost.

Product Detail

Engine		TE150
Model		Cummins QSF3.8-C115
Rated Power	kW/rpm	86/2200
Max.torque	kN.m/rpm	470/1400
Hydraulic System
Working pressure	Mpa	34.3
Max. flow rate	L/min	*1282**
Operating Performance
Swing speed	rpm	11.9
Traveling speed(High/Low)	km/h	5.3/3.1
Max.digging force (Bucket)	kN	100
Max.digging force (Arm)	kN	68
Gradeability	%	70
Max.drawing force	kN	138
Overall Dimensions
A Overall Length	mm	7762
B Overall Width	mm	2510
C Overall Height	mm	2983
F Ground Clearance of counter weight	mm	915
I Length of platform	mm	2306
D Width of platform	mm	2510
E Overall height of cab	mm	2825
I’ Rear Swing Radius	mm	2387
Travelling Part
K Length of Track shoe	mm	3751
J Wheel base of Track shoe	mm	3010
M Track Gauge	mm	1990
N Width of Track shoe	mm	500
Ground Pressure	kgf/cm²	0.423
H Min. ground clearance	mm	416
Tank Capacity
Fuel Tank	L	280
Hydraulic Tank	L	165
Max.digging reach	8335mm
Max.digging reach on the ground	8203mm
Max.digging depth	5491mm
BMax.valid digging depth	5288mm
Max.vertical digging depth	4826mm
Max.digging height	8679mm
Max.dumping height	6174mm
Min.swing radius	2605mm
