CNCMC TE350 35 Ton Crawler Excavator

Introduction:

High-power engine and strong digging force for heavy-duty working conditions.
Stable and heavy-duty structure ensures long service life and high reliability.
High working efficiency and strong performance in mining and large projects.
Low fuel consumption and easy maintenance to reduce operating cost.
Wide application with strong adaptability to various attachments and worksites.

Product Detail

Product Tags

Specifications	TE350	A Overall length	10806mm
Operating weight	35000kg	B Overall width	3280mm
Standard bucket capacity	1.7m³	C Overall height of boom	3546mm
Engine		D With of platform	3060mm
Model	CUMMINS 6LTAA8.9	E Overall height of cab	3145mm
Type	Turbo-charged with inter-cooled	F Ground clearance of counterweight	1193mm
Power	241KW/2000rpm	H Min.ground clearance	2640mm
Max.torque	1400N.m @ 1400rpm	G Height of engine cover	471mm
No.of cylinders	6	I Length of platform	3325mm
Displacement	8900cc	I’Rear swing radius	3370mm
Hydraulic system		J Track wheelbase distance	4030mm
Main pump:		K Chassis length	4950mm
Type	Variable displacement axial piston pumps	L Chassis width	3280mm
Max.displacement	2x140cc/rev	M Track gauge	2680mm
Working pressure	32.3/34.3Mpa	N standard width of track shoe	600mm
Hydraulic motor		Max.digging reach	10233mm
Swing	axial piston motor	Max.digging depth	6536mm
Travel	axial piston motor	Max.vertical wall digging depth	4758mm
Performance		Max.digging height	9617mm
Swing speed	10rpm	Max.dumping height	6666mm
Max.travel speed H/L	5.1/3.1km/h	Min.swing radius	4256mm
Gradeability	35°
Max.digging force of bucket	225kN
Max.digging force of arm	182kN
Ground pressure	61.9kpa
Tank capacity
Fuel tank capcity	520L
Hydraulic tank capacity	280L
