CNCMC TE500 50 Ton Crawler Excavator

Super strong digging force and high efficiency for heavy-duty mining and large projects.
Heavy-duty reinforced structure ensures high stability and long service life.
Powerful engine and reliable performance under extreme working conditions.
Low fuel consumption and easy maintenance to lower operating cost.
Wide application with strong adaptability to various heavy-duty attachments.

Product Detail

Specifications	TE500	Walking device
Operating weight	47300kg	K Track length	5470mm
Standard bucket capacity	2.22m³	J Track wheelbase	4470mm
Engine		M Track gauge	2740mm
Model	QSM11-C375	N Track width	600mm
Rated power	298/2000kW/rpm	H Minimum ground clearance	560mm
Max. torque	1898/1400kN.m/rpm	Tank capacity
Hydraulic system		Fuel	680L
Worling pressure	32.3/34.3Mpa	Hydraulic oil	380L
Max. flow	2x360cc/rew	Max. digging depth	12027mm
Performance		Max.ground diggng reach	11830mm
Rotating speed	10rpm	Max. digging depth	7862mm
Travelling speed	4.6/2.8km/h	Max. vertical digging depth	6691mm
Max.digging force（Bucket）	290kN	Max. digging height	10897mm
Max.digging force （Stick）	255kN	Max.dumping height	7897mm
Gradeability	35%	Min.turning radius	4868mm
Ground pressure	76.5Kpa
Dimensions
A Length	12032mm
B Width	3340mm
C Height	3639mm
F Counterweight ground cleanrance	1230mm
I Platform length	3605mm
D Upper width	3215mm
E Cab height	3314mm
I’ Rear swing radius	3450mm
