CNCMC TG180 180hp Motor Grader

CNCMC TG180 180hp Motor Grader Featured Image
  • CNCMC TG180 180hp Motor Grader

Introduction:

  • 180HP engine with sufficient power and strong traction.
  • High leveling accuracy, stable and efficient in operation.
  • Wide application for road, site, airport and mining area work.
  • Flexible control, good mobility and easy operation.
  • Sturdy structure, reliable durability and low running cost.


Product Detail

Product Tags

Model TG180
Engine model Cummins 6BTA5.9-C180
Rated power 132KW@2200rpm
Dimension(L×W×H) 8820×2600×3420(mm)
Operating weight(Standard) 14500KG
Travelling speed ,forward 6.5/11.4/14.6/24.8/30/49.2
Travelling speed ,reverse 6.5/14.6/30
Tractive force(f=0.75) 74.6KN
Max. steering angle of front wheels 49°
Max. lean angle of front wheels 17°
Max. oscillation angle of front axle 16°
Max. oscillation angle of balance box 13°
Frame articulation angle 26°
Min. turning radius using articulation 7.3m
Maximum lift above ground 450mm
Maximum grading depth 535mm
Maximum blade position angle 90°
Blade cutting angle 29°~77°
Circle reversing rotation 360°
Moldboard width × height 3658×580mm
