CNCMC TL50 5 Ton Wheel Loader

Introduction:

Compact structure and flexible operation in narrow construction sites.
Stable loading capacity with high efficiency for daily working tasks.
Low fuel consumption and easy maintenance, reducing operation cost.
Good mobility and convenient transportation between different job sites.
Wide application in construction, farming, landscaping and material handling.

Product Detail

Product Tags

HYDRAULIC SYSTEM	TL30	ENGINE	TL30
Type	Mechanical work control or joystick control	Maker/Model	WEICHAI/WP6G125E22
System Pressure	16MPa	Rated Power	92kW/2200rpm
CycleTime(Sec)	9	Maximum Torque	500N.m/1400-1600rpm
BRAKE SYSTEM		Bore x Stroke	105x130mm
ServiceBrake	Gas Push Oil Caliper Brake	No.of Cylinders/Displacement	6/6.75L
Parking Brake	Flexible Shaft Controlled Caliper Brake	DRIVE TRAIN
REFILL CAPACITY		TransmissionType	Countershaft Powershift
FuelTank	200L	Shift Type	Soft axis Powershift Control
Hydraulic Tank	165L	Torque Converter Type	Single-stage&turbine,3-element
Crankshaft	14L	TravelSpeed-Forward	7/12/24/36 km/h
Transmission	36L	TravelSpeed-Reverse	8.5/28 km/h
Front Axle/Rear Axle	18.5L/18.5L	STEERING SYSTEM
WORKING EQUIPMENT		Type	Hydraulic Load Sensing System
Breakout Force	105(95)±3kN	Steering Angle	±35°
Configuration	STD,High Dump	System Pressure	14MPa
Overall Height-Bucket Raised	4735mm,5040mm	Min.Turning Radius over Bucket	6250mm
Bucket Pin Height at Max.Lift	3725mm,4034mm	Min.Turning Radius over Tires	5695mm
DumpClearanceatMax.Lift(45°)	2930mm,3240mm	TIRE
Reach at Max.Liftand 45°Dump	1070mm,1010mm	Tire	17.5-25L-3 12PR TT
Digging Depth	30-40mm,30-40mm	Wheel Base	2850mm
AXLES		Width at Tread Center	1850mm
Strengtheneddry-type front and rear axles standard.		Overall Width over Tires	2320mm
Traction Force	97±3kN
Max.gradientcapacity	26°
