CNCMC TL6 6 Ton Wheel Loader

Introduction:

Strong loading capacity and high efficiency for heavy-duty working tasks.
Stable structure and strong power ensure reliable long-term operation.
Good adaptability to construction, mining, port and earthmoving projects.
Low fuel consumption and easy maintenance to reduce operating cost.
Excellent performance with durable key parts for long service life.

Product Detail

Product Tags

Overall Dimension	TL60	Working Hydraulic System	TL60
Length(with bucket on ground)	8714(mm)	Model of oil pump	JHPg3100/Gj1020-XF
Width(to outside of wheels)	2900(mm)	System pressure	20MPa
Bucket width	3048(mm)	Model of Muti-way directional valve	D32Ⅱ-YL20
Height(To the top of the cab)	3550(mm)	Pilot valve	DXS-00
Wheel base	3300(mm)	Steering System
Min. ground clearance	498(mm)	Model of steering pump	JHP2080S
Technical Specification		Model of redirector	BZZ3-E100B
Rated load	6000(Kg)	Model of priority valve	ZLF25A11
Operating weight	19500KG	System pressure	16MPa
Rated bucket capacity	3.7(m ³), optional 2.6-5.0 (m ³)	Brake System
Max. dump clearance	3393(mm)	Type of traveling brake	Caliper disc brake
Dump reach	1365(mm)	Air pressure	6-7.5 (KGF/cm2)
Min. turning radius(wheel)	6240(mm)	Type of parking brake	Manual control cutting-off air brake
Diesel engine		Oil Capacity
Model	ShangChai SC11CB240.1G2B1	Fuel(diesel)	350(L)
Type	Direct injection	Engine lubricating oil	24(L)
Rated output	175 (kW)	Oil for converter and gear box	45(L)
Total exhaust of cylinder	10.5 (L)	Oil for hydraulic system	245 (L
Rated speed	2200(r/min)	Oil for driving axles (F/R)	30/24(L)
Max. Torque	912(N.M)@1400 r/min
Transmission System
Model	ZF 4WG200
Type	3-elements single stage
Gear shift position	4F, 3R
Speed (F/R)	6.6/6.6, 11.8/11.8, 24.1/24.1, 38.6
Max. drawing force	180kN
Size of tire	23.5-25-20 pr
