CNCMC TMZ330 330 Ton Mining Dump Truck
| Specification | TMZ240 | Specification | TMZ330 |
| Overall Dimensions | 15000×8700×7800 mm | Overall Dimensions | 15000×9300×7600 mm |
| Drive Type | 4×2 Rear Axle Drive | Drive Type | 4×2 Rear Axle Drive |
| Vehicle Operating Weight | 178 t | Vehicle Operating Weight | 210 t |
| Loading Capacity | 210-230 t | Loading Capacity | 300-330 t |
| Maximum Speed | 64.5 km/h | Maximum Speed | 64.5 km/h |
| Rated Gradability | 8% | Rated Gradability | 8% |
| Maximum Gradability | 18% | Maximum Gradability | 18% |
| Braking Distance | <25 m @ 30 km/h – 0 km/h | Braking Distance | <26 m @ 30 km/h – 0 km/h |
| Braking System | Electric Brake & Mechanical Brake | Braking System | Electric Brake & Mechanical Brake |
| Bucket Capacity | Struck: 110 m³ | Bucket Capacity | Struck: 175 m³ |
| SAE 2:1 Loose: 130 m³ | SAE 2:1 Loose: 215 m³ | ||
| Hydraulic Tank Capacity | 900 L | Hydraulic Tank Capacity | 1040 L |
| Operating Temperature | -40℃ to 50℃ | Operating Temperature | -40℃ to 50℃ |
| Engine Model | QST60/MTU16V4000 | Engine Model | QST30 |
| Engine Power | 1865 kW | Engine Power | 2013 kW hp |
