CNCMC TR12 12 Ton Single Drum Roller Vibratory Road Compactor

Introduction:

Suitable for compaction of large-scale engineering foundations such as high-grade roads, dams, railways, airports, etc. It can crush non-stick materials such as sand, gravel, gravel, rock fill and semi-stick materials.

●Equipped with 4-cylinder supercharged Weichai power, with large power reserve, high efficiency, energy saving and environmental protection, and the emission reaches the national standard II.

●Mechanical drive, three speeds. Hydraulic vibration, electric control, vibration, large centrifugal force, good compaction performance; Hydraulic steering, articulated frame, light and flexible steering, light and flexible operation.

●Equipped with a special gearbox for the roller with a synchronizer, which has large transmission torque and light shifting; Gas-assisted hydraulic caliper disc driving brake, mechanical parking drum brake, safe and reliable.

●Optional different pattern tires; optional other brands of diesel engines; standard cab, optional air conditioning. Optional bump type steel wheel.

Inquiry

Product Detail

Product Tags

Operating weight	10000/ 10500 kg
Vibratory drum diameter	1430 /1630mm
Compaction width	1980 mm
Static line pressure	240 /290 N/cm
Min. ground clearance	380mm
Wheel base	2900/2980 mm
Min. turning radius	5800 mm
Gradeability	30%
Vibratory amplitude	1.6/0.8mm 1.4/0.7mm
Vibratory frequency	30 Hz
Centrifugal force	225/105 kN
Travelling speed
（Forward）	Ⅰ/Ⅱ/Ⅲ 2.0/4.2/8.7 km/h
（Reverse）	Ⅰ/Ⅱ 2.0/4.2 km/h
Tyre model	17.5-25-12PR
Engine model	WEICHAI WP4G110E221
Rated power	82kW
Rated speed	2000 r/min
