CNCMC TRSH12/14 12/14 Ton Full Hydraulic Single Drum Road Roller

CNCMC TRSH12/14 12/14 Ton Full Hydraulic Single Drum Road Roller Featured Image
  • CNCMC TRSH12/14 12/14 Ton Full Hydraulic Single Drum Road Roller

Introduction:

        5 Core Advantages of 12T / 14T Full-Hydraulic Single-Drum Roller

  • Full hydraulic system for stable, precise and easy operation.
  • Strong compaction force for solid, high-density subgrade.
  • Excellent traction on soil, gravel and uneven sites.
  • High efficiency for large earthwork and roadbase construction.
  • Reliable structure, long service life and low maintenance cost.


Product Detail

Product Tags

Specification   TRSH12 TRSH14
Operating mass kg 12000 14000
Static linear load N/cm 326 373
Vibrating frequency Hz 32/29 32/29
Amplitude mm 1.7/0.8 1.7/0.8
Centrifugal force kN 260/160 280/180
Gradeability % 35 35
Min.turning radius mm 7000 7000
Max.travel speed km/h 10 10
Drum width*diameter mm 2100*1500 2100*1500
Diesel model   Cummins 6BT5.9 Cummins 6BT5.9
Diesel power kW 110 110
Diesel rotational speed r/min 2200 2200
Overall dimensions mm 5900*2250*3000 5900*2250*3000
