One of Hottest for Forklift Truck - Heli 38-46t Heavy Forklift-series G series internal combustion counterbalanced forklift – China Construction Detail:
1 ) Design standard : Designed by a well-known European port machinery design company , which is synchronized with the technical level of similar European products in the same period . The design standard not only meets national standards , but also meets EU standards ( EN1459ISO15018 ) , with higher safety
( 2 ) Power system : using imported VOLVO engine with strong power ;
( 3 ) Gearbox : It adopts DANA original imported gearbox , adopts electrohydraulic shift control system , stable operation and high reliability
( 4 )Drive axle : the heavy-duty drive axle from KESSLER , Germany , has a large carrying capacity , and is equipped with a fully enclosed maintenance-free wet brake , which is safe and reliable , and has a long service life
( 5 ) Hydraulic system : adopts Parker variable system , high efficiency and energy saving ,
( 6 ) Safety assistance system : standard visual reversing warning system ,sate and reliable ;
(7 ) high-strength structural parts : the frame structure designed with high-strength plates is durable
( 8 ) Large maintenance space : raise the cab and tilt the hood to fully release the internal maintenance space
|
Model |
Unit |
CP CD 380-vd2-12IlI |
CP CD 400-vd2-12IlI |
CP CD 420-vd-12IlI |
CP CD 460-vd-12IlI |
CP CD 420-vd2-12IlI |
CP CD 460-vd2-12IlI |
|
|
Load center |
mm |
1200 |
1200 |
1200 |
1200 |
1200 |
1200 |
|
|
Load capacity |
kg |
38000 |
40000 |
42000 |
46000 |
42000 |
46000 |
|
|
Lifting height(standard) |
mm |
4000 |
4000 |
4000 |
4000 |
4000 |
4000 |
|
|
Lifting speed(load) |
mm/s |
280 |
280 |
240 |
240 |
240 |
240 |
|
|
Mast tilt angle F/R |
Grad |
6/10 |
6/10 |
6/10 |
6/10 |
6/10 |
6/10 |
|
|
Engine |
|
volvo |
volvo |
volvo |
volvo |
volvo |
volvo |
|
|
Overall dimensions |
Overall Length(with fork) |
mm |
9870 |
9870 |
10370 |
10370 |
10370 |
10370 |
|
|
Overall Width |
mm |
4120 |
4120 |
4120 |
4120 |
4120 |
4120 |
|
|
Height with mast lowered |
mm |
4600 |
4600 |
4850 |
4850 |
4850 |
4850 |
