Wholesale Price China Dual Axle Flatbed Trailer - CNCMC 40 Ton Mining truck with loading capacity and high comprehensive efficiency CN855D – China Construction Detail:

Model CN855D
Gross vehicle weight(T) 65
Weight
Rated payload(T) 42
Curb weight(T) 23
Overall dimensions (LxWxH) mm 8870×3200×3730
 Main  parameters
Wheel base (mm) 3600+1500
Driving type 6×4
Max.speed (km/h) 42
Min.turning radius 11
Max. gradeability 36%
Min. ground clearance (mm) 355
Braking Length(30km/h) m 15
Apporach/Departure Angle (°) 33/48
Type Weichai WP12.380 (Euro III Emission)
Engine
Model Inline, six-cylinder, four-stroke water-cooled direct injection turbo-charged diesel engine
Displacement(L) 11.596
HP 380
Transmission FAST 7DS180+QH70B
 Main Configurations
Clutch Eton 430
Front axle 13T HANDE axle, integral welding structure front axle
Middle & rear axle 25T+25T HANDE axle, double hub reducer cast steel axle
Cabin Single whole rigid narrow left cabin
Steering System Double Steering System
Electric System 12V×2 electric system, maintenance-free battery
Lifting System HYVA Alpha
Bucket capacity: 25m³ , with rear door. Size: 5500×2950×1500 mm; Bottom plate thickness 16mm, rear plate, front & side plate thickness 10mm,T700 high strength plate.
Specification of the cargo body
Fuel Tank  (L) 400
Tire size 14.00-25-36PR
Body paint color Engineering Yellow
