OEM Customized Auger - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction

Introduction:

Product Detail

Product Tags

Feedback (2)

We keep on with our business spirit of "Quality, Performance, Innovation and Integrity". We goal to create much more worth for our customers with our rich resources, state-of-the-art machinery, experienced workers and exceptional providers for Track Loader Backhoe, High Track Dozer, Off Highway Truck, All products are manufactured with advanced equipment and strict QC procedures in order to ensure high quality. Welcome customers new and old to contact us for business cooperation.

OEM Customized Auger - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction Detail:

Model		LLC220	LLC223	LLC226	LLC228
Total weight	kg	20000	23000	26000	28000
Front wheel axle load	kg	9500	11000	12500	13500
Rear wheel axle load	kg	10500	12000	13500	14500
Long	mm	7355	7355	8150	8150
Width	mm	3000	3000	3800	3800
High	mm	3600	3600	3650	3650
Wheelbase	mm	3350	3350	3500	3500
Ground clearance	mm	435	435	490	490
Width of pressure roller(front/rear)	mm	1040/835	1040/835	1195/970	1195/970
Diameter of pressure roller(front/rear)	mm	1500/1500	1500/1500	1620/1620	1620/1620
Number of teeth of pressing wheel(front/rear)		50/40	50/40	50/40	50/40
Engine manufacturer		SHANGCHAI	SHANGCHAI	SHANGCHAI	SHANGCHAI
Engine model		SC8DK200G3	SC8DK200G3	SC9DK260G3	SC9DK260G3
Engine power	kw	147	147	192	192
Engine speed	r/min	2200	2200	2200	2200
1 Forward speed	km/h	0-4.2	0-4.2	0-4.41	0-4.41
2 Forward speed	km/h	0-10	0-10	0-7.1	0-7.1
3 Forward speed				0-10.87	0-10.87
Reverse speed 1 gear	km/h	0-5.8	0-5.8	0-4.41	0-4.41
Reverse speed 2 gear				0-7.1	0-7.1
Maximum climbing ability	%	100	100	100	100
Dozer height	mm	1650	1650	1880	1880
Dozer width	mm	3000	3000	3800	3800
Dozer lifting height	mm	1000	1000	1200	1200
Dozer depth	mm	150	150	200	200
Steering angle	±°	40	40	40	40
Lateral swing angle	±°	15	15	15	15
Turning radius(outside front wheel)	mm	6250	6250	7200	7200
Fuel tank	L	450	450	500	500
Hydraulic tank	L	236	236	236	236
Drive method		Hydraulic transmission,power shift,all-wheel drive
Service brake		Pneumatic push oil,four-wheel caliper disc brake
Parking/emergency braking		Mechanical,expanding shoe brake
Steering method		Hydraulic,central articulated,swingable

6 (1)
6 (2)
6 (3)
6 (4)
6 (6)
6 (5)
6 (7)
6 (8)
6 (9)

Product detail pictures:

Related Product Guide:

Being supported by an advanced and professional IT team, we could offer technical support on pre-sales & after-sales service for OEM Customized Auger - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction , The product will supply to all over the world, such as: Peru, Swansea, Iran, We set "be a creditable practitioner to achieve the continuous development and innovation" as our motto. We would like to share our experience with friends at home and abroad, as a way to create a bigger cake with our joint efforts. We have several experienced R & D persons and we welcome OEM orders.
