Heli 14-18t Heavy Forklift-seriesG series light internal combustioncounterbalanced forklift ( For Southeast Asia

Introduction:

1 . Power system : adopts Dongfeng Cummins 6BTAA5 9-C170 power ,which meets the National I emission standards , has strong power and strong weather resistance . This engine enjoys the support of Cummins global joint warranty service system

2 . Fuel system : In addition to the engines own primary filter , an additional primary filter is added to better meet the requirements of low fuel quality


Product Detail

Product Tags

Video

Product intro

1 . Power system : adopts Dongfeng Cummins 6BTAA5 9-C170 power ,which meets the National I emission standards , has strong power and strong weather resistance . This engine enjoys the support of Cummins global joint warranty service system

2 . Fuel system : In addition to the engines own primary filter , an additional primary filter is added to better meet the requirements of low fuel quality

3 . Gearbox : It adopts the enhanced manual-automatic gearbox independently developed by Heli , which is reliable , safe and easy to maintain

4 . The special drive axle for heavy-duty forklifts is adopted to meet the needs of continuous operation under severe working conditions

5 . Hydraulic system : adopt Italian company hydraulic system , high effciency and energy saving

6 . Braking system : The caliper disc brake system adopting air-over-oil technology is safe and reliable

7 . High-strength structural parts of the body system : the frame structure with high-strength plates and box-shaped design is adopted , which is more durable

8 . Hood Double flip the hood to fully release the internal maintenance Space

9 . Wheel system : 12.00-24 pneumatic tires are standard configuration for the whole series . The ground clearance of the truck is increased , which has better pass ability . The front and rear tires and rims are consistent and interchangeable . The whole machine can be equipped with a reserved spare tire installation position

Main Performance Parameters

Model

Unit

CP CD 140-cu-06IIg

CP CD 150-cu-06IIg

CP CD 160-cu-06IIg

CP CD 180-cu-06IIg

Load center

mm

600

600

600

600

Load capacity

kg

14000

15000

16000

18000

Lifting height(standard)

mm

3000

3000

3000

3000

Lifting speed(load)

mm/s

300

300

300

300

Mast tilt angle F/R

Grad

6/12

6/12

6/12

6/12

Engine

Dongfeng Commins

Dongfeng Commins

Dongfeng Commins

CDongfeng Commins

Overall dimensions

Overall Length(with fork)

mm

6335

6335

6335

6335

Overall Width

mm

2780

2780

2780

2780

Height with mast lowered

mm

3280

3280

3280

3280

Product Display

1
3

FAQ

HOW IS YOUR PRODUCT QUALITY COMPARED WITH OTHERS' ?

We are a state-owned company with good reputation, all of our products are good quality with cost-effective price. Any after-sales service problems, you can contact us directly without hesitation.

HOW LONG IS OUR PRODUCT WARRANTY ?

The guaranteed period for the main parts of our new machine is 12 months commencing from the issue date of the Bill of loading or within 1500 working hours, depends on whichever occurs first.

The main pars include: the engine, the hydraulic pumps, hydraulic control system, all kinds of hydraulic valves, hydraulic motors, hydraulic gear pumps, hydraulic cylinders, radiator, all pipes and hoses, chassis and shafts, quick-attach system and attachments, etc.

WHAT ARE THE TERMS OF AFTER SALES SERVICE ?

During the guaranteed period, service of guarantee will be supplied on condition that the machine itself appears to have defects. We will supply the maintenance component parts of the machine free of charge.

We also offer engineer training and technology supporting during machine all life

Overseas engineer service is also available if it is agreed by both parties.

HOW LONG IS THE DELIVERY TIME ?

In the case of stock, the delivery time is 7 days after receipt of the balance. In the case of non-stock, the delivery time is 25 days

WHICH PAYMENT TERMS CAN WE ACCEPT ?

Normally we can accept T/T term or L/C term.

(1) On T/T term. 30% by T/T as down payment , the balance will be paid before shipment.

(2) On L/C term. Irrevocable Letter of Credit at sight.
