XCMG 6ton XE60WA Wheel Excavator

Introduction:

As an important member of small excavator series products, XE60WA wheeled hydraulic excavator has multiple functions, such as backhoe excavating, crushing, drilling and clamping, and meanwhile it has advantages of easy transfer, low energy consumption, flexibility and adaptability, as well as low price, light weight and convenient maintenance.

XE60WA is powered by a high-efficiency direct injection Yanmar 4tnv-98 engine, which has been carefully designed and commissioned to achieve sustained, stable and powerful power transmission at low speeds. Powerful torque can meet the hydraulic system requirements and achieve faster working cycle.


Product Detail

Product Tags

Video

Performance Characteristics

XE60WA adopts hydraulic load sensitive system, with excellent electronic control pump, the engine power is perfectly matched, so that it can start more smoothly, work better, and consume less oil.

Adopting highly specialized design and analysis tools, combined with bench tests to ensure the durability of our machines. The strength and toughness of the material and structure of the product has been strictly tested under the most extreme conditions. Rigid robot welding structure ensures excellent durability of products. The counterweight and stable parts like dozer blade and outrigger have been strictly calculated and tested to ensure the durability and stability of the machine.

Advanced ROPS certified cab with sun shade, rearview mirror and adjustable suspension seat will ensure operator’s safety. Strong air-conditioning system, in line with ergonomic switch layout, will improve driving comfort.

1
2

Specifications

Model

unit

XE60WA

Operating weight

Kg

5900

Bucket capacity

0.23

Engine

Model

/

Yanmar

4TNV98

No.of cylinders

/

4

Rated power/speed

kw/rpm

42.5/2400

Maxium Torque/swing speed

N.m

201/1800

Displacement

L

3.319

Main performance

Travel speed(H/L)

km/h

30/10.5

Swing speed

r/min

10

Gradeability

°

≤30

Bucket digging force

kN

42.8

Arm digging force

kN

25.8

Hydraulic System

Main pump

/

150

Rated flow

L/min

150

Main safety valve pressure

MPa

22

Travel system pressure

MPa

22

Swing system pressure

MPa

22

Pilot system pressure

MPa

3

Oil Capacity

Fuel tank capacity

L

110

Hydraulic tank capacity

L

120

Engine oil capacity

L

7

Appearance size

Total length

mm

6230

Total width

mm

1925

Total height

mm

2850

Width of platform

mm

1845

Total width of chassis

mm

1925

Counterweight clearance

mm

970

Working scope

Max. digging height

mm

5830

Max. dumping height

mm

4240

Max. digging depth

mm

3520

Max. vertical wall digging depth

mm

2400

Max. digging radius

mm

6120

Min. swing radius

mm

2510

Standard

Boom Length

mm

3000

Arm Length

mm

1600

Bucket Capacity

0.23
